UNI-T UT33D+ Palm Size Digital Multimeter with NCV Tester, Backlit LCD, AC/DC Voltage, Resistance & Continuity Detector
The UNI-T UT33D+ is a compact, palm-sized digital multimeter engineered for electrical troubleshooting, solar maintenance, and electronic repairs. Featuring non-contact voltage (NCV) detection, an illuminated LCD display, 2-meter drop protection, and clear acoustic continuity testing, it provides reliable measurements for voltage, current, and resistance with high precision.
Rs 4,200Rs 4,800Save Rs 600
Warranty
Standard Dealer
Model
UT33D+ (Palm Size Multimeter)
Availability
In Stock
Product Description
Take the guesswork out of electrical troubleshooting with the UNI-T UT33D+ Palm Size Digital Multimeter. Built with a rugged ergonomic housing designed to survive 2-meter drops, this upgraded UT33+ series meter sets a higher standard for safety, durability, and testing performance in residential, automotive, and solar PV maintenance.
The UT33D+ features an integrated Non-Contact Voltage (NCV) detector that allows technicians to identify live AC wires without direct metallic contact, ensuring user safety. Its crisp 1999-count LCD screen includes a bright backlight for effortless reading in dim distribution panels or unlit inverter rooms. Equipped to measure AC/DC voltage up to 600V, DC current up to 10A, and resistance up to 200MΩ, it also delivers responsive acoustic continuity buzzer testing, diode evaluation, and data hold functionality. Whether diagnosing inverter lines, testing battery bank terminals, or verifying circuit continuity, the UNI-T UT33D+ is an essential tool for electricians, solar installers, and DIY technicians.
Specifications
Brand:UNI-T
Model:UT33D+
Display Count:1999 counts LCD with Backlight
DC Voltage ($V_{DC}$):200mV / 2000mV / 20V / 200V / 600V
AC Voltage ($V_{AC}$):200V / 600V
DC Current ($A_{DC}$):2000µA / 20mA / 200mA / 10A (Fused 10A Max)
Resistance ($\Omega$):200Ω / 2000Ω / 20kΩ / 200kΩ / 20MΩ / 200MΩ
Non-Contact Voltage (NCV):Built-in NCV sensor with visual/audible alert
Continuity Buzzer:Acoustic beep indication with fast response
Diode Test:Integrated diode test mode
Data Hold:Dedicated HOLD/SEL push button
Safety Rating:CAT II 600V / 2m Drop Proof Certified
Form Factor:Palm-sized compact handheld design
Key Features
- Integrated Non-Contact Voltage (NCV) detection for contactless testing of live wires.
- Crisp, high-contrast backlit LCD screen for optimal visibility in dark environments.
- Rugged protective outer casing tested and rated for 2-meter drop impact resistance.
- Accurate AC/DC voltage testing up to 600V for solar inverters, DB boxes, and home appliances.
- Fast acoustic buzzer for swift continuity and open/short-circuit detection.
- Wide resistance measurement range extending up to 200MΩ.
- Data Hold (HOLD/SEL) function locks readings on-screen for easy recording.
- Fused input terminal design with dedicated probe holder grooves for safe, organized field operation.
